LH Series Triaxial Elliptical Screen

Three axis elliptical vibrating screen is a screening equipment designed and developed on the basis of circular vibrating screen and linear screen by integrating their advantages. Its motion track is elliptical, with high blocking prevention and screening accuracy. It is suitable for screening processes that require high material accuracy.

request a quote e-mail

Advantages

  • The elliptical vibration track integrates the advantages of circular vibration screen and linear vibration screen;

  • The three-axis vibrator is linked by chrome nickel alloy gear, and the external eccentric block is easy to adjust;

  • The maximum vibration intensity is 6.0G, bringing better screening effect and preventing mesh blockage;

  • Horizontal installation, applicable to sites with limited installation height.

Completely new design of HXZG

  •
	 Vibration Track

    Vibration Track

Technical Specifications

Model Screen mesh size Motor power/kw Number of plies Rotating speed Amplitude Vibration intensity Installation angle Separation particle size Maximum feeding size
2LH1860 1800x6000 37 2 645-875rpm 14-18mm maximum 6.0G 2-130mm 150mm
3LH1860 1800x6000 37 3 645-875rpm 14-18mm maximum 6.0G 2-130mm 150mm
2LH2060 2100x6000 37 2 645-875rpm 14-18mm maximum 6.0G 2-130mm 150mm
3LH2060 2100x6000 45 3 645-875rpm 14-18mm maximum 6.0G 2-130mm 150mm
2LH2460 2400x6000 45 2 645-875rpm 14-18mm maximum 6.0G 2-130mm 150mm
3LH2460 2400x6000 45 3 645-875rpm 14-18mm maximum 6.0G 2-130mm 150mm

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Model Screen mesh size Motor power/kw Maximum feeding size
2LH1860 1800x6000 37 150mm
3LH1860 1800x6000 37 150mm
2LH2160 2100x6000 37 150mm
3LH2160 2100x6000 45 150mm
2LH2460 2400x6000 45 150mm
3LH2460 2400x6000 45 150mm

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
